This modular bevel storage box has the characteristics of folding resistance, anti-aging, high loading strength, stretching, compression, tearing, high temperature, rich color, lightness, durability and stacking. We can make molds for all kinds of specifications and sizes according to the user's requirements, which can be capped, dust proof and beautiful in appearance. The features of mold design are as below: 1. The cavity is made with insert part which is to process and maintenance in future. 2. Stripper plate for balancing ejection. 3. The protruding part of plastic box is used as the insert, which can release and exhaust the air, making it easier to eject the product. 4. High efficient cooling circular design for shortening cycle time. 5. Excellent NC processing to increase the assembly precise of mold to reduce flash.

The bathroom corner shelf is well-designed. The shape is triangle, which is appropriate to assemble in the corner. It has three spaces and two covers. For the first compartment it is out of cover, which is suitable for the waterproof commodity such as toothbrush set and shampoo whose size is taller. For the second compartment, you are suggested to put toilet paper and sanitary product into for preventing them from wet. As to the last also the smallest compartment, it is the best place to keep soap inside. At the bottom of the shelf has three hooks, you can hang towels, bath ball or anything you need in your bathroom.

The mold is simple 2-plate mold structure, but because it is a puzzle product, there are a lot of small parts, the positions between parts and the pouring points are very skillful, if the arrangement is not good, there will be flash problems, air trap problem. Products are ejected out by pins. There are many ejectors in this mold, so ejector balance of ejector plate is very important. The most characteristic is that the mold runner is also a part of the product, is the product frame and fixed base.

Laundry Basket Size: 489.2 X 622.7 X 233.9mm Basket Weight: 0.59 kgs Gate system: 5 tips Hot Runner Not all molding applications are suitable for runner-less molding. Some materials are heat sensitive and the time to temperature relationship - especially when the shot size is very small - can be a problem. Some families of parts, for handling and orientation purposes, may be best kept attached to the runner until they reach another downstream operation. In other instances, the required volume of parts may be so small that the added cost of the hot runner system to the mold price cannot be justified.

Focare Mould specializes in plastic soap box mould and household injection mould manufacturing, offering hot runner systems, reliable ejection solutions and customized mould designs.

By filling this shower head on watering can with water, the flowers will have regular water. Its grid is made to allow flowers to not be damaged by too much water flow. Fix to watering can's spout for excellent watering flow control and a fine spray. The plastic shower head is divided into two parts, one is the shower head, and the other is the body.

20L water bucket mold with durable and adjustable mold structure which significantly prolong mold life and shorten cycle time which mold is designed with efficient cooling channel.

Paint bucket mould and plastic moulding painting bucket. The technical point for the painting bucket is the painting bucket wall eccentric and ejection system. Paint bucket is different as all the other kinds of bucket, there is one undercut on the edge of the bucket mouth, and this undercut (rib) need to be stripped before it drop down.

Product size: 242.3 X 336.7 X 183.2 Product weight: 265.7g Core/Cavity Steel: 718H Product material: PP Injection: Cold runner
